Features of DSM Camera


  • Adopt 1/2.9" 2053D 200W image sensor

  • Support HD video (AHD TVI CVI CVBS HD standard);

  • Support 1080P@25, 1080P@30;

  • Low illumination,0.01 Lux@(F1.2, AGC ON), 0 Lux IR;

  • Support black and white 940 infrared light;

  • Adopt high-definition lens (6mm/lens);

  • High-quality LED infrared light, the farthest irradiation distance is 1~2 meters;

  • Support 3D noise reduction, superior low-light performance;

  • Support automatic white balance function, vivid image;

  • Vehicle shockproof design, aviation head output

Specification of DSM Camera


model


Basic specification

sensor type

1/3 inch low illumination 2 million pixel CMOS image sensor

Minimum illumination

0.01 Lux @ (F1.2, AGC ON) , 0 Lux with IR

shutter

1/25 second to 1/50,000 second

Lens

6mm

Lens interface type

M12

Noise reduction mode

Support 3D noise reduction

Day and night conversion mode

Black and white

Video frame rate

1080p@25fps

Synchronously

Internal synchronization

S/N ratio

42dB

External   Interface

Video input

AHD Coaxial HD (aviation head)

Audio input

Built-in MIC

Power Output

12V

Aviation headline sequence

1-video;2-Audio;3-power supply;4-Ground(Corresponding to aviation head interface number)

General specification

Working temperature and humidity

-20℃~75℃,90%

power supply

DC9V-16V

Power consumption

175MAH

Rear view lens

Infrared irradiation distance

1-2M

weight

〉500g

waterproof

IP66
